Power & Performance
Maximizes power and efficiency by spraying fuel at high pressure directly into the combustion chamber.
A three-stage low-medium-high pressure fuel pump system works, in part, due to two independent, rpm-activated fuel pumps in the Vapor Separator Tank. This unique five-pump system creates an unprecedented fuel injection pressure of up to 2900 PSI to further maximize atomization and efficiency.
Intake tracks enter the cylinder head from the outside of the powerhead. This gives exhaust gases room for a direct route to the lower unit and out through the propeller hub, streamlining the powerhead and improving flow.
With diameters from 16 to 17 1/8 inches and increased blade surface, XTO propellers complement the torque potential of our V8 XTO Offshore. They also contribute to greater thrust overall, including up to 300 percent more reverse thrust than the Yamaha F350.
Convenience & Control
In-water Gear Lube Change System
For the ultimate convenience, a technician can drain and replace your outboard’s lower-unit lubricant without having to remove your boat from the water.
Thrust-enhancing Exhaust Routing
For more control at lower speeds and increased precision of our Helm Master® EX boat control system, exhaust is diverted away from the propeller at RPMs below 2,500.
Pump Stop Power Tilt Limit
The tilt pump shuts off when it reaches maximum tilt setting, rather than continuing to run, saving power and reducing noise at full trim in/out.
Dual Flush System
A unique design offers two methods for flushing the XTO, either through a built-in flushing system hose routed through the rigging tube/grommet or through conventional front-mounted direct-hose hook-up.
Wide-span Powerhead Mounting System
For minimized vibration and a more compact design, incredibly strong upper motor mounts placed wide on the exterior of the upper mid-section work in conjunction with our Long Span Mounting System.
Phase Angle Control Charging
The XTO’s NEW Phase Angle Control Charging System meets the extreme electrical needs of today’s larger boats. This Innovation Award-winning new system produces up to 96 amps of net charging power at idle—from a single outboard—and up to 480 net amps in a quint configuration. This is up to 65 percent more maximum net charge at idle than the previous XTO model.
Improved Rigging Tube
A redesigned rigging tube provides an extra 3.25 inches of clearance at the motor well when tilted up, and is compatible with most flat-transom installations.
Specifications
| Engine Type | V8 / DOHC / 32 valves / 4 Valves per Cylinder |
| Displacement | 5.6L |
| Bore x Stroke | 96 x 96 mm (3.78 x 3.78 in) |
| Prop Shaft Horsepower | 425hp at 5500 RPM |
| Full Throttle RPM Range | 5000 – 6000 RPM |
| Alternator Output at W.O.T. | 100 Amp Gross, Max |
| Compression Ratio | 12.2:1 |
| Fuel Induction System | Direct Injection / Up to 2900 PSI |
| Max Output | 312.60KW |
| Recommended Fuel | Octane 89 |
| Recommended Engine Oil | Yamalube® 4M |
| Recommended Fuel Filtration | Water Separating Filter (external) |
| C.A.R.B. Rating | 3-Star |
| Exhaust | Through Propeller (Except in Reverse Under 2500 RPM) |
| Intake | 32 |
| Ignition | TCI Microcomputer |
| Spark Plug | ILMAR7E-9 / Iridium |
| Alternator Output | Up to 96 amps net/ 100 amps gross, max |
| Starting System | Electric w/ PTT |
| Lubrication | Wet Sump |
| Engine Oil Capacity | 7.8L / 8.2 Quarts | 7.5L / 7.9 Quarts |
| Recommended Cooling | Thermostatic Control |
| Ethanol Blend Limit | 10% Maximum |
| Gear Ratio | (25/14) 1.79 |
| Gear Shift | Forward, Neutral, Reverse |
| Shaft Length | 25″ – 30″ – 35″ |
| Degree of Tilt | -4° through +73° |
| Degree of Trim | -4° through +16° |
| Dry Weight | 432 kg – 453 kg |
| Mounting Centers | 28.5″ |
| Steering | Integrated, Electric Actuation |
| Steering Angle (maximum) | 31° from center, either direction |
| Warranty | Limited 5-Year, 1-Year Commercial |
